small scale incinerators

The incinerator burn waste in primary combustion chamber and burn the smoke from primary combustion chamber again to make sure environmentally friendly with no black smoke, smelless, reduce pathogenic bacteria infection.

System solutions for medical waste environmental, including waste incineration, smoke emission treatment, high-temperature sterilization, ultraviolet sterilization lamp, waste shredder, needle destroyer, medical waste package, sharp containers, etc.

The pet cremation equipment humanized design with movable platform, small space covers for modern pet cremation business owner all over the world.

The containerized mobile incinerator mounted in ISO container before leave factory, pre-installation, no incineration house build construction, movable by truck and ultraviolet lamp sterilization inside.


Items/Model

TS10(PLC)

TS20(PLC)

TS30(PLC)

TS50(PLC)

TS100(PLC)

Burn Rate (Average)

10 kg/hour

20 kg/hour

30 kg/hour

50 kg/hour

100 kg/hour

Feed Capacity(Average)

20kg

40kg

60kg

100kg

200 kg

Control Mode

PLC

PLC

PLC

PLC

PLC

Combustion Chamber

100L

210L

330L

560L

1200L

Internal Dimensions

50x50x40cm

65x65x50cm

75x75x60cm

100x80x70cm

120x100x100cm

Secondary Chamber

50L

110L

180L

280L

600L

Smoke Filter Chamber

Yes

Yes

Yes

Yes

Yes

Feed Mode

Manual

Manual

Manual

Manual

Manual

Voltage

220V

220V

220V

220V

220V

Power

0.5Kw

0.5Kw

0.5Kw

0.7Kw

0.7Kw

Oil Consumption (kg/hour)

5.4–12.6

7.8–16.3

10.2–20

12.1–24

14–28

Gas Consumption (m3/hour)

6.2–11.4

8–15.7

9.8–20

9.9–26.1

10–32.2

Temperature Monitor

Yes

Yes

Yes

Yes

Yes

Temperature Protection

Yes

Yes

Yes

Yes

Yes

Oil Tank

100L

100L

100L

100L

200L

Feed Door

30x30cm

45x40cm

55x50cm

70x55cm

80x60cm

Chimney

3Meter

3Meter

5Meter

5Meter

10Meter

Chimney Type

Stainless Steel

Stainless Steel

Stainless Steel

Stainless Steel

Stainless Steel

1st. Chamber Temperature

800-1000

800-1000

800-1000

800-1000

800-1000

2nd. Chamber Temperature

1000-1200

1000-1200

1000-1200

1000-1200

1000-1200

Residency Time

2.0 Sec.

2.0 Sec.

2.0 Sec.

2.0 Sec.

2.0 Sec.

Gross Weight

1500kg

2200kg

3000kg

4500kg

6000kg

External Dimensions

140x90x120cm

160x110x130cm

175x120x140cm

230x130x155cm

260x150x180cm
