What is Incinerator?

The incinerators are constructed with well insulated and heavy materials so that it does not give off extreme amounts of external heat. The high levels of heat are kept inside the unit or furnace so that the trash and waste gets burnt off easily and quickly. This helps in increasing the efficiency .



so what is incinerator? The incinerator or the furnace is designed to dispose of waste effectively . This helps to eliminate the high cost associated with having it hauled away and deposited somewhere else that piles even more trash atop at existing landfills or sites.



Incinerator incinerate and dispose many waste types such as medical, industrial, general, animal and household wastes, thus incinerator machine can be used in hospitals, farms, industrial areas, constriction sites, etc.



Incinerators also help to serve to keep dangerous materials from finding their ways to landfills that have ability to harm people including the people who work at the landfill sites and those operate the incinerators.


Items/Model

YD-200

YD-300

YD-500

YD-600

Burning Rate (kgs/Hour)

200 kgs/Hr.

300 kgs/Hr.

500 kgs/Hr.

600 kgs/Hr.

Feed Capacity (kgs)

400 kgs

500 kgs

800 kgs

1100 kgs

Equipment Weight

7600 kgs

8300 kgs

13000 kgs

16500 kgs

Primary Chamber (Liters)

2000

2400

4000

5500

Secondary Chamber (Liters)

500

1200

1500

1500

External Dimensions (cm)

270 x 185 x 380

260x220x420

320x220x460

360 x 220 x 475

Internal Dimensions (cm)

180 x 115 x 96

220x110x100

257x147x108

300 x 147 x 125

Oil Tank(Liters)

300

500

500

500

Door Opening (cm)

59 x 81

90 x 110

108 x 128

108 x 128

Chimney (M)

10

10

14

14

Chimney Type

Stainless Steel

Stainless Steel

Stainless Steel

Stainless Steel

Secondary Chamber

YES

YES

YES

YES

Mix-Combustion Chamber

YES

YES

YES

YES

Smoke Filter Chamber

YES

YES

YES

YES

Combustion Fuel

Oil/Gas

Oil/Gas

Oil/Gas

Oil/Gas

Residency Time

2.0 Sec.

2.0 Sec.

2.0 Sec.

2.0 Sec.

Temperature Monitoring

YES

YES

YES

YES

1st. Chmaber Temperature

800-1000

800-1000

800-1000

800-1000

2nd. Chmaber Temperature

1000-1200

1000-1200

1000-1200

1000-1200
